STEMME S 10-VT: Performance & Dimensions
External Dimensions
Wing span 23.00 m (75 ft 5½ in)
Wing aspect ratio 29.29
Width, wings folded 11.40 m (37 ft 4½ in)
Length over-all 8.42 m (27 ft 7½ in)
Fuselage max width 1.18 m (3 ft 10½ in)
Height over-all 1.80 m (5 ft 10½ in)
Wheel track 1.15 m (3 ft 9¼ in)
Wheel base 5.42 m (17 ft 9½ in)
Propeller diameter 1.63 m (5 ft 4¼ in)
Internal Dimensions
Cockpit width 1.16 m (3 ft 9½ in)
Cockpit height 0.93 m (3 ft ½ in)
Areas
Wings, gross 18.70 m2 (201.3 sq ft)
Horizontal tail, gross 1.46 m2 (15.8 sq ft)
Vertical tail, gross 1.51 m2 (16.3 sq ft)
Weights and Loadings
Weight empty: 660 kg (1,455 lb)
Max. take-off and landing weight: 850 kg (1,874 lb)
Max. wing loading: 45.5 kg/m2 (9.31 lb/sq ft)
Max. power loading: 10.06 kg/kW (16.53 lb/hp)
General Performance
Never-exceed speed (VNE): 146 kt (270 km/h; 168 mph)
Manoeuvring speed: 97 kt (180 km/h; 112 mph)
Stalling speed (flaps in landing position): 42 kt (78 km/h; 48 mph) G-limits: +5.3/-2.65
Powered Performance
Max. cruising speed at MSL: 121 kt (225 km/h; 139 mph)
Max. cruising speed at FL100: 140 kt (248 km/h; 154 mph)
Max rate of climb at S/L and MTOW: 4.14 m/s (817 ft/min)
Service ceiling: 30,000 ft (9,140 m)
T/O-run (MSL, ISA, MTOW): 205 m (675 ft)
T/O-distance (MSL, ISA, MTOW): 447 m (1470 ft)
Max range with standard fuel (2x45 ltr): 697 nm (1,290 km)
Max range with extended fuel (2x60 ltr): 929 nm (1,720 km)
Unpowered Performance
Best glide ratio at 57 kt (106 km/h; 66 mph) Up to 50
Min rate of sink at 45 kt (83 km/h; 52 mph) Down to 112 ft/min (0.57 m/s)
As found on www.stemme.de
External Dimensions
Wing span 23.00 m (75 ft 5½ in)
Wing aspect ratio 29.29
Width, wings folded 11.40 m (37 ft 4½ in)
Length over-all 8.42 m (27 ft 7½ in)
Fuselage max width 1.18 m (3 ft 10½ in)
Height over-all 1.80 m (5 ft 10½ in)
Wheel track 1.15 m (3 ft 9¼ in)
Wheel base 5.42 m (17 ft 9½ in)
Propeller diameter 1.63 m (5 ft 4¼ in)
Internal Dimensions
Cockpit width 1.16 m (3 ft 9½ in)
Cockpit height 0.93 m (3 ft ½ in)
Areas
Wings, gross 18.70 m2 (201.3 sq ft)
Horizontal tail, gross 1.46 m2 (15.8 sq ft)
Vertical tail, gross 1.51 m2 (16.3 sq ft)
Weights and Loadings
Weight empty: 660 kg (1,455 lb)
Max. take-off and landing weight: 850 kg (1,874 lb)
Max. wing loading: 45.5 kg/m2 (9.31 lb/sq ft)
Max. power loading: 10.06 kg/kW (16.53 lb/hp)
General Performance
Never-exceed speed (VNE): 146 kt (270 km/h; 168 mph)
Manoeuvring speed: 97 kt (180 km/h; 112 mph)
Stalling speed (flaps in landing position): 42 kt (78 km/h; 48 mph) G-limits: +5.3/-2.65
Powered Performance
Max. cruising speed at MSL: 121 kt (225 km/h; 139 mph)
Max. cruising speed at FL100: 140 kt (248 km/h; 154 mph)
Max rate of climb at S/L and MTOW: 4.14 m/s (817 ft/min)
Service ceiling: 30,000 ft (9,140 m)
T/O-run (MSL, ISA, MTOW): 205 m (675 ft)
T/O-distance (MSL, ISA, MTOW): 447 m (1470 ft)
Max range with standard fuel (2x45 ltr): 697 nm (1,290 km)
Max range with extended fuel (2x60 ltr): 929 nm (1,720 km)
Unpowered Performance
Best glide ratio at 57 kt (106 km/h; 66 mph) Up to 50
Min rate of sink at 45 kt (83 km/h; 52 mph) Down to 112 ft/min (0.57 m/s)
As found on www.stemme.de
Serious inquiries: contact Neal @ info@bachmanairworks.com.
Other Equiptment
Carbon fiber oxygen bottle
Winglets
Cockpit heating
Position and strobe lighting
Landing light
Solar panel
Engine Rotax 914F
Air brakes
Retractable landing gear
Variable pitch retractable propeller
Two 12 volt batteries
4-point seat belt
Carbon fiber oxygen bottle
Winglets
Cockpit heating
Position and strobe lighting
Landing light
Solar panel
Engine Rotax 914F
Air brakes
Retractable landing gear
Variable pitch retractable propeller
Two 12 volt batteries
4-point seat belt
Instrumentation
Winter 5STVM5-3 Variometer
Cambridge L-NAV Soaring Computer
Cambridge LS-RO Add Indicator S/C
Westerboer Speed control-Stall warning
GPS Skyforce Skymap II
Becker AR 4201 Comm radio
FlightCom Intercom
Cambridge GPS CAI 25
Winter 5STVM5-3 Variometer
Cambridge L-NAV Soaring Computer
Cambridge LS-RO Add Indicator S/C
Westerboer Speed control-Stall warning
GPS Skyforce Skymap II
Becker AR 4201 Comm radio
FlightCom Intercom
Cambridge GPS CAI 25
SOLD!
